CONCRETE BLOCK AND PAVER MACHINE

RH
1450

HESS Group

RH 1450

RESOURCE-SAVING SOLUTION WITH MAXIMUM PERFORMANCE.

The RH 1450 stands out due to its cost efficiency, achieved through better material utilization and enhanced performance.

This efficiency allows for reduced investment costs while still retaining the benefits of a large board plant – particularly when paired with an appropriate handling system.

PLANT LAYOUT

1 2 3 4 5 6 7 8 9 10

1 Aggregate silos

2 Mixing plant

3 Machine RH 1450 VA

4 Elevator

5 Finger car

6 Curing racks

7 Lowerator

8 Cuber servo 700-2

9 Production board displacer with buffer conveyor

10 Frame conveyor with frames

		RH 1450
Production board (mm)**		1,400 x 1,100
Production area (mm)**		1,300 x 1,050
Min. product height (mm)		40
Max. product height (mm)		500
Machine weight in VA version (kg)		38,000
Paving stone 10x20x5cm without face mix:	Cycle time (s)	12.5
	m² in 8h	2,114
	Quantity of stones/mold	54
Paving stone 10x20x6cm with face mix:	Cycle time (s)	14.5
	m² in 8h	1,823
	Quantity of stones/mold	54
Hollow block 20x40x20cm	Cycle time (s)	16.5
	Quantity in 8h	17,800
	Quantity of stones/mold	12
Production output is calculated based on 85 percent machine availability and is significantly influenced by machine settings, the concrete mixing recipe used, the quality of raw materials, the performance of other related plant equipment, mold characteristics, the stone format, and the production pallets used. Technical Data are subject to change. ** Other production board sizes available.
